12 10/100TX + 2 10/100/1000T X coded w/8/16 PoE at/af EN50155 Ethernet Switch; 24VI / 24TVI model
- EN50155/61373/45545-2 verification
- IEEE802.3at/af up to 30W PoE output
- Dual 9~36VDC (24VI model) or 16.8~56VDC (24TVI model) input selection
- Wide Operating Temperature from -40°C to 75°C
- IP54 Aluminum housing for best heat dissipation and preventing moist ingress
- E-mark* certificate for vehicle (24VI model)
- ITxPT** design w/ ignition function (24VI-IGN model)
OVERVIEW
Lantech T(P)ES-0212T is a 12 10/100Base-TX + 2 10/100/1000 Base-T w/8/16 port 802.3at/af PoE ports with M12-connectors unmanaged EN50155 Ethernet switch with IP54 rated protection which meets the high reliability requirements demanded by industrial rolling stock applications.
Up to @30W PoE+ output with 8/16 PoE ports
The TPES-0212T supports IEEE802.3at/af standard which can feed HI-power up to 30W at each PoE port (8/16 ports in total) for various IP PD devices.
PoE galvanic isolation up to 1.5KVDC to provide power input to PoE Ethernet ports insulation prevents cabling and grounding incidents from damaging the Ethernet switch itself.
E-marking* certificate; ISO 7637-2 compliant and extended working temperature
The T(P)ES-0212T is designed to meet with critical network environment with IP54 enclosure and M12 connectors for protection against dust and water. It has passed harsh environmental testing to comply with Industrial EMI and Safety standards as well as stability testing such as Free fall, Shock, and vibration. It is compliant with ISO 7637-2 which protects switch from being damaged by high voltage that could be found at vehicle cranky start. For a greater flexibility in application the T(P)ES-0212T supports an extended operating temperature range from -40°C to 75°C.
The E-marking* certificate makes it the most suitable switch for bus, carriage, other vehicles application as well as for industrial areas where the power source is limited with 12V or 24V but has demand of IP surveillance or VoIP applications.
EN50155, EN45545-2, EN61373 verification; High ESD protection
Lantech T(P)ES-0212T features high reliability and robustness coping with extensive EMI/RFI phenomenon, environmental vibration and shocks usually found in factory, substation, steel automation, aviation, mining and process control. It is the best solution for Automation, transportation, surveillance, Wireless backhaul, Semi-conductor factory and assembly lines.
ITxPT** design with Ignition function using software
T(P)ES-0212T is designed with ITxPT public transport standards and also compliant with ISO 7637-2 which protects switch from being damaged by high voltage that could be found at vehicle cranky start. (24VI-IGN model)
Lantech is dedicated to providing the best quality and service to our customers. We proudly provide 5 years warranty to our industrial products.
